Destructor for the OdGeEntity3d class. (Inherited from OdGeEntity3d)

This is the overview for the closestPointTo method overload.

Returns a copy of this entity. (Inherited from OdGeEntity3d)

Returns the distance to the point on this curve closest to the specified point.

This is the overview for the evalPoint method overload.

Returns the point on this surface closest to the specified point.

This is the overview for the getEnvelope method overload.

Returns bounding box of the whole surface or a part of it. The box is axis-aligned in the specified local coordinate system. It is guaranteed to enclose the surface, but not guaranteed to be tight/minimal.

Finds all poles of surface. Surface envelope not considered. In case of NurbSurface extreme points of envelope are checked. Input arrays may be not empty. In this case new poles will be written to the ends of the arrays.

Returns true if and only if this surface is closed in the U direction.

Returns true if and only if this surface is closed in the V direction.

Checks whether the specified entity is equal to this one.
(Inherited from OdGeEntity3d)

Returns true if and only if this entity is of type (or is derived from) entType.
(Inherited from OdGeEntity3d)

Checks orientation of the surface.

Checks normal direction.

Returns true if and only if the specified point is on this entity, as determined by the tolerance.
(Inherited from OdGeEntity3d)

Determines if the passed point is on this surface and retrieves a 2D point that represents parametric values for the passed 3D point if it is on this surface.

This is the overview for the makeIsoparamCurve method overload.

Mirrors this entity about the specified plane, and returns a reference to this entity.
(Inherited from OdGeEntity3d)

This is the overview for the paramOf method overload.

Projects a point onto this surface.

Reverses the normal of this surface.

Rotates this entity by the specified angle about the axis defined by the point and the vector, and returns a reference to this entity.
(Inherited from OdGeEntity3d)

Scales this entity by the scale factor about the basepoint, and returns a reference to this entity.
(Inherited from OdGeEntity3d)

Set the rectangle in parameter space that defines the parameter domain of this surface.

Applies the 3D transformation matrix to this entity, and returns a reference to this entity.
(Inherited from OdGeEntity3d)

Applies the 3D translation vector to this entity, and returns a reference to this entity.
(Inherited from OdGeEntity3d)

Returns the entity type. (Inherited from OdGeEntity3d)

Comparison operator for the OdGeEntity3d object.
(Inherited from OdGeEntity3d)

Assignment operator for the OdGeEntity3d object.
(Inherited from OdGeEntity3d)

Assignment operator for the OdGeSurface class.

Comparison operator for the OdGeEntity3d object.
(Inherited from OdGeEntity3d)
